Brand Name : Perfect Laser
Model Number : PE-W600D
Certification : CE
Place of Origin : China
MOQ : 1 SET
Price : Negotiable
Payment Terms : T/T, L/C, PayPal, Western Union
Supply Ability : 500 sets per month
Delivery Time : 10-15 working days
Packaging Details : Sea-Worthy Packing or Air-Worthy Packing
Model : PE-W300II 500II Advertising Letter Laser Welding Machine
Laser wave-length : 1064nm Double Welding Path
Pulse width : 0.3-20ms
Power consumed : ≤9KW
Laser Cavity : UK imported “Morgen” Brand
Laser Lamp : Single lamp OR Double lamp
Standard worktable : 800*1000mm
Positioning : CCD Screen + Red Dot Pointer
Single power energy : 100J OR 120J
Max laser power : 300W OR 500W
360 Degree Rotating Laser Head Boom Type Die Stainless Steel Cymbal Steel Precious Metal Mould Laser Welding Machine
(Model: PE-W600D)
★ Product Introduction:
The mould laser welding machine is specially designed for precision die repair, such as digital products, mobile phones, toys, automobiles, motorcycles and other die manufacturing and forming industries. Through the mold repair, the original mold can be fully utilized, greatly saving production costs and improve work efficiency. This technology can also be used to modify the mold design or size, reduce the product development cycle.
★ Features:
1.The diameter of the mould laser welding machine spot is adjustable, and the laser welding has high precision, high precision and high strength.
2.The laser head and optical part can be rotated 360°, up/down lifting and forward/backward push, suitable for repairing large, medium and small molds.
3.No bumps on the welding surface. No need for polishing and grinding process, saving working time. The appearance is very beautiful.
4.The mould laser welding machine uses 1064nm wavelength laser, which is harmless to human body.
5.To make up for the shortcomings of traditional argon arc welding, cold welding is fine in repairing the surface of the weld, and the oxidation efficiency is low, and the work does not change color.
6.Equipped with a cross cursor stereo microscope, the welding position is magnified 10 times, (15 times, 20 times optional), small parts are clear at a glance.
7.The center of the cross cursor overlaps with the center of the laser spot for easy positioning.
★ Application:
The mould laser welding machine is suitable for large, medium and small molds of welding, aluminium welding. This types of welding machine is widely used in chassis, automobiles, tires, ships, large household appliances plastic shell, auto parts, bearings, construction machinery and other mold manufacturing and molding industry. This types of welding machine can repair welding a variety of mold steel, stainless steel, cymbals steel, precious metals and hard materials, aluminium welding. Precision injection molding, die-casting, mold repair and accessories, precision stamping parts of the welding, lost wax castings, aluminum castings, stainless steel products sand hole.
★ Technical Parameters:
Model | PE-W600D Mould Laser Welding Machine |
Input voltage | Three-phase four wire system,380V±5% |
Maximum input power | 16KW |
All mirror | reflectivity≥99.7% |
Power feedback type | current feedback |
Condenser cavity | Gold single cavity design, double lamp single rod |
Laser wavelength | 1.064μm |
Beam divergence angle | ≤8mrad/m |
Peak output power | 500W |
Laser head adjustment | 360 degree |
Pulse frequency | 1~150Hz |
pulse width | 0.1~20ms |
Current regulation | 50-500A |
Beam expander | 3 times |
Focal spot diameter | 0.2-2mm |
Cantilever stretch length | 900mm |
Cantilever up and down travel | 1000mm |
Cantilever XY electric stroke | 150*150mm |
Laser cavity length | 600mm |
Table size | X*Y=500mm*350mm |
Table travel | 200mm |
Table XY hand travel | 250*120mm |
Display mode | Coaxial microscope+CCD observation |
Positioning mode | Red |
★ Machine parts:
★ Packaging & Delivery:
1. Prompt deliver at the very day.
2. Well-trained and disciplined packing team.
3. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
4. Sophisticated and professional logistic agent.
★Competitive Advantages:
1. 100% custom pass guaranteed.
2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
3. Flexible and Untraceable payment terms.
4. Good after-sale service.
5. We offer high quality products at competitive price in quick delivery.
![]() |
