Fully Automatic Corrugated Honeycomb Cardboard Gray Board Coated Paper Sponge CNC Oscillating Vibration Knife Cutting Machine
Model: PE-1410
★ Machine Introduction
This intelligent vibration knife cutting machine is an innovative product from Perfect Laser. It comes with professional graphic editing and processing software that converts design drawings into PLT format files recognized by the machine, enabling data transmission via a network cable connection. The vibration knife cutting machine supports various tool options, including vibration knives, milling cutters, and pressure wheels, to meet the cutting needs of different materials. By setting parameters through the cutting software, users can start efficient and accurate cutting operations.
★ Machine Features
1. High performance: Equipped with imported servo motors and drivers to ensure stable equipment quality and performance, providing long-lasting and reliable power support.
2. Versatility: The oscillating knife cutting machine integrates multiple functions such as cutting, creasing, V-grooving, pen writing, etc., to achieve multi-purpose use of one machine and meet diverse production needs.
3. Precise positioning: The oscillating knife cutting machine supports cutting at any point with precise material placement and high cutting accuracy, achieving ±0.02mm repeatability and machine precision.
4. Strong durability: Made with 5052 aviation-grade aluminum for the honeycomb worktable to maintain flatness and extend service life. The oscillating knife cutting machine also uses 10 million times of high-flexible cables to ensure long-term and stable operation.
5. Easy operation: Easy-to-install software with an intuitive interface. Once parameters are set, the oscillating knife cutting machine can be operated independently within 30 minutes, improving overall efficiency.
6. Safe and reliable: Equipped with multiple safety configurations such as an emergency stop button, infrared sensing, leakage protection to ensure smooth machine aoperation and operator safety.
7. High efficiency and energy saving: The oscillating knife cutting machine's rated total power is under 7.5KW, which reduces energy consumption while ensuring high cutting efficiency, in line with the concept of green production.
8. Convenient tool replacement: Tool replacement is easy and fast, completed through simple actions like inserting, removing, and locking, which minimizes downtime and boosts productivity.
★ Appliaction
1. Application industry
The oscillating knife cutting machine's efficient cutting speed and precise cutting accuracy make this machine have a wide range of application prospects in packaging, advertising, printing, handicraft production and other industries.
2. Application materials
The intelligent oscillating knife cutting machine is widely used in cutting various paper types such as corrugated cardboard, honeycomb cardboard, cardboard, gray board paper, coated paper, as well as various flexible non-metallic materials such as pearl cotton, EVA, sponge, etc.
★ Technical Data
| Product Name | Intelligent Oscillating Knife Cutting Machine |
| Product Model | PE-1410 |
| Translation Speed | 0-1500mm/s |
| Cutting Speed | 0-800mm/s (Varies With Different Thicknesses and Materials) |
| Cutting Thickness | ≤40mm (Thickness Can Be Increased According To Customer Requirements) |
| Repeatability Accuracy | ±0.02mm |
| Machine Accuracy | ±0.02mm |
| Rated Total Power | ≤7.5KW |
| Working Voltage | AC 380V±10% 50Hz (Distribution Box Selected According to Customer's Actual Voltage) |
| Effective Working Range | 1400mm(L) * 1000mm(W) |
| Overall Dimensions | 2250mm(L) * 1850mm(W) * 1280mm(H) (Height adjustable) |
★ Packaging & Delivery
1. Prompt deliver at the very day.
2. Sophisticated and professional logistic agent.
3. Well-trained and disciplined packing team.
4. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
★ Competitive Advantages
1. We offer high quality products at competitive price in quick delivery.
2. 100% custom pass guaranteed.
3. Good after-sale service.
4. Flexible and Untraceable payment terms.
5. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
|
|
Fully Automatic Cardboard EVA Sponge CNC Vibration Oscillating Knife Cutting Machine Images
|
